Eagle PH Series Hydraulic Press

Overview

The Eagle PH Series are heavy-duty hydraulic presses designed specifically for try-out, die-spotting, mold making, and stamping die verification work. These machines combine precision, strength, and flexibility to support demanding tooling and die applications. Built by Eagle with rugged steel plate construction, and in your choice of post-type or straight-sided, gib-guided frame styles, the PH Series delivers both safety and performance.

Key Features & Highlights

Here are what make the PH Series stand out:

• Custom Frame & Rigid Construction
  • Heavy steel-plate frames, optional straight-sided or post-type, fully gib-guided for alignment under heavy loads.
• PLC Controls + Manifold-Hydraulics
  • Modern PLC (programmable logic controller) packages, crown-mounted manifold hydraulic systems, and state-of-the-art control logic.

Standard & Optional Enhancements:

• Centralized lubrication for smoother long-term maintenance.
• Rolling bolsters, pivoting upper platens, and slide locking devices for safe, efficient die handling.
• Options in bed size, shut height, stroke length designed to match your tooling.
• Versatile Applications – Perfect for injection/compression molds, stamping dies, diecut/die cast verification, plus tasks in deep draws, tool & die try-outs, etc.
• Wide Capacity & Custom-Sized Configurations – Eagle offers PH presses in very large tonnage (3000+ tons) for big tools; bed and slide dimensions are built to your specs.

Applications & Use Cases

• Verifying die geometry under pressure: spotting stamping dies, injection/compression molds, die-cast dies.
• Try-outs and corrections: material flow, closure/fits, tool alignment.
• Industries with large or complex tooling: automotive, appliances, aerospace, heavy equipment.
• Shops needing flexibility: frequently changing dies or molds, tight tolerances, repeatability.

Why Choose Eagle SE Series?

• Deep experience & reputation: Eagle has built spotting, try-out, and hydraulic presses since 1959.
• Highly customizable: built to suit the bed size, force, travel, and tooling you have.
• Safety / operator convenience: modern controls, lubrication, locking, and handling options.
• Long-term reliability: rigid frame design, quality hydraulic components, good support network in North America.

Typical Spec Checkpoints

When selecting or specifying a PH Series Die-Spotting Press, these specs are key:

1. Tonnage / Pressing Force: Must be sufficient to close the die/tool without deflection & with safety margin.
2. Stroke Length / Travel: Determines how far the ram/platen moves, and if it fits your tooling dimensions.
3. Shut Height & Daylight Opening: Die height + required clearance; needed for spotting operations & die removal.
4. Bed Area (L-R, F-B): To accommodate the die footprint, plates, handling, and operator access.
5. Frame Type (Post vs Straight-Sided): Influences space, rigidity, ease of maintenance, and cost.
6. Control Features & Safety Options: Slide locking, platen pivoting, sensors, hydraulic safety interlocks, etc.
7. Die-Handling Enhancements: Rolling bolsters, pivot platens, etc., for quicker setup and safer operations.

Example Specifications

Here’s a snapshot of a real PH Series Press to give you a sense of scale:

• Model: PH2-200-118-48 (200 tons)
• Stroke: 48"
• Bed Area: 134" × 48" (L-R × F-B)
• Daylight Opening: ~ 68″
• Fast Approach / Return Speeds: High approach / return rates (for efficient spotting operations)

Contact & Ordering

If you’re considering a PH Series Press for your facility, we can help you size and configure one that matches your needs. To get started, send us:

• Your die or mold dimensions & weight
• Required force / tonnage and cycle expectations
• Desired stroke, shut height, and daylight needs
• Control / operator safety preferences (locking, platen options, etc.)
• Any environmental or layout constraints

Reach out to PRI today to discuss how the Eagle PH Series can help you improve die accuracy, reduce try-out time, and raise overall production quality.
