Production Resources Fall 2020 News

PRI Swift Pages HeaderWINTRISS Die Protection Clinic

Now available as a Webinar

Until we can do them in-person again, we’re offering our Die Protection Clinic
as an online webinar!

Learn the most effective methods tor sensing:

Non-ejected parts
Short and Long Feed problems
Part transfer
Stripper position
Slug ejection
Cam return
Ejection cylinders position
Double blanks
Material buckling
Pulled slugs

Learn more here:

Shop Floor Connect Version 6 released.

New look & New Features

ShopFloorConnect ® is the Complete Solution for automatic downtime tracking for
All Machines.

Intuitive control easily adapts to any machine
Unlimited users. Collects uptime, downtime, and production counts automatically with no operator involvement
Scalable system; designed for any size factory
Multi-Site capable;connect all your plants into one system
Provides production data in real time, and supports “visualfactory” displays

Get the full product brochure here:

Comparison of Version 6 to Version 5

Typical Shop Floor Connect Screen shown belowFactory ViewerClick for a larger view.

Linear Transfer Automation New Product

Linear has announced that it has forged a strategic alliance with Strothmann Automation of Germany. Strothmann and Linear have entered into an exclusive technology agreement for the North American market for the Compact Crossbar and the high-speed Tandem Press Line Automation products from Strothmann.

The Strothmann Innovative feeder for press lines lowers production costs.
This feeder can do more than simply load and unload presses: The FeederPlus 6neo can also center blanks and deposit workpieces in the correct orientation. This reduces the costs and space requirements of press lines significantly.

The starting point was the FeederPlus 6, which has been used with great success in a total of 11 press lines for 10 years. Through further development into the FeederPlus 6neo the feeder was adapted to the current demands of modern press plants. The feeder is designed for max. 16 strokes/min. A sophisticated combination of state-of-the-art mechanics and highly-developed software allows the feeder to perform functions in the FoL and EoL, which would otherwise require bulky, expensive additional components.

Call us for your press room, automation, safety, and conveying equipment needs

Accra Wire – pallet decoilers

Coe Press Equipment Corp. – coil feeding and handling

Dorner – low profile conveyors

Green Valley – die carts & die racks

Linear Transfer Automation – transfer and destacking

MPI – electric shaker conveyors

Pascal – quick die change

Pax Products – conveyors and lubrication systems

Rapid Air – coil feeding and handling

Seyi Press – servo and conventional power presses

Wintriss Controls – automation and safety controls

Call Chris Jones 615-714-1000 or email for:
In plant application assistance, OSHA/ANSI compliance surveys, and Quotes.

256 Seaboard Ln
STE B-104
Franklin, TN 37067
