MPI Electric Shaker Conveyors

Overview

MPI electric shaker conveyors, from Magnetic Products, Inc. (MPI) of Highland, Michigan, clear slugs and trim scrap from under the die on stamping presses. The press-mounted M-10, M-50 and M-200 lock into the bolster T-slots and drive a crossbar-and-pan system from a standard 110V plug, while the floor-mounted M-10000 Series carries scrap long distances to a central collection point. Production Resources, Inc. (PRI) supplies the MPI shaker line and helps match each model to the press and die it will serve.

For background on how shaker conveyors work and where they fit in scrap handling, see PRI's electric shaker conveyor systems guide.

Patented MPI Shaker in Action

Key Features

• Patented press-mounted drive
  • The M-10, M-50 and M-200 share a patented electric drive (U.S. Patent 8,752,695 B2): a slow forward stroke and quick return walk scrap to the discharge end.
• No shop air or lubrication
  • MPI reports operating costs up to 71% lower than pneumatic shaker designs.
• T-slot mounting, plug-in power
  • The drive slides into the bolster T-slots, locks with a bolt and plugs into a standard 110V outlet.
• Pans that move with the die
  • Pans ride an extruded aluminum crossbar on Quick Release Pan Mount Brackets, slide into position between the die uprights and lock by hand.
• Reversible flow
  • To send scrap the other way, unmount the drive, rotate it 180 degrees and remount it.
• Quiet, simple operation
  • The drive runs almost silently and starts from a side-mounted on/off switch, or from the press controls.

Product Line / Models

MPI offers four electric shaker series, sized by crossbar width and scrap volume:

• M-10 – compact drive for smaller presses using up to an 18-inch crossbar.
• M-50 – medium-sized presses with up to a 36-inch crossbar; speed is factory preset.
• M-200 Rack and Pinion – medium to large presses; the rack and pinion evens out lopsided pan loads.
• M-10000 Series – floor-mounted, high-capacity conveyor for underground and central scrap systems.

M-10 Electric Scrap Shaker

The smallest drive in the line has a heavy-duty steel build yet is light enough to carry by hand. The M-10-18 system comes with an 18-inch crossbar and is rated for 10 lb of pans and scrap combined.

M-10 electric scrap shaker datasheet (PDF)

M-50 Electric Scrap Shaker

The M-50 doubles the crossbar to 36 inches and carries 50 lb of pans and scrap. MPI often pairs it with a steel belt conveyor, beltless magnetic conveyor or underground shaker to build a complete scrap line.

M-50 electric scrap shaker datasheet (PDF)

M-200 Rack and Pinion Electric Scrap Shaker

The M-200 handles 200 lb of pans and scrap on crossbars from 48 to 180 inches; sizes from 72 inches up include the rack and pinion. The drive is built from 1-inch-thick billet aluminum. An optional height-adjustable cart lets the crew roll the system between presses without a forklift.

M-200 rack and pinion shaker datasheet (PDF)

M-10000 Series Floor-Mounted Shaker

The M-10000 moves more than 10,000 lb of scrap per hour over runs of hundreds of feet, using one continuous steel pan and a single drive scaled up from the M-series design. Grease-free Rubber Suspension Technology (RST) bearings carry the pan, and MPI supports each system from site assessment through installation.

M-10000 Series floor-mounted shaker datasheet (PDF)

Applications & Benefits

• Slug and trim removal: pans between the die uprights carry scrap out of the press.
• Oily stampings: rigidized carbon steel pans help break the oil's surface tension so parts keep moving.
• Frequent die changes: quick-release brackets let operators add, remove or shift pans between jobs.
• Presses without spare air capacity: the press-mounted drives need only 110V power, not compressed air.
• Plant-wide scrap handling: the M-10000 teams with incline conveyors and controls in underground and central scrap systems.

Technical Specifications (from MPI Datasheets)

Values below come from MPI's current published datasheets; MPI notes that specifications are subject to change.

MPI rates the M-50 and M-200 at a 20 ft/min conveying speed. Key M-10000 Series values:

• Maximum design speed: 15 ft/min, with slower speeds available
• Assembled pan length: up to 250 ft with a 24-in. pan, or 200 ft with a 36-in. pan
• Standard pans: troughed, 24 or 36 in. wide by 6 or 12 in. deep; or rectangular, 24 or 36 in. wide with 6-in. side guides
• Pan material: 10-gauge carbon steel (standard), 10-gauge stainless, 7-gauge manganese steel, or carbon steel with a replaceable rigidized, AR or composite liner

How to Choose the Right MPI Electric Shaker

1. Crossbar width: 18 in. (M-10), 36 in. (M-50) or 48 to 180 in. (M-200).
2. Load: pan weight plus scrap weight against the 10, 50 or 200 lb design capacity.
3. Pan balance: MPI recommends balanced loads on the M-10 and M-50; uneven layouts call for the M-200.
4. Bolster T-slots: confirm slot size against the mounts supplied.
5. Changeover: one bracket set per pan, plus a cart if an M-200 moves between presses.
6. Scrap destination: a hopper or downstream conveyor, or a plant-wide M-10000 system.
7. Oil and wear: rigidized pans for oily parts; wear pad kits where pans ride on the bolster.

Why MPI Electric Shakers Are Trusted

• Patented design: U.S. Patent 8,752,695 B2 covers the M-series drive, and the M-10000 drive is a scaled-up version of it.
• Modular build: if something fails, a modular drive gets the press running again quickly.
• Factory backing: MPI runs a repair program and a 24/7 support line.

Additional Resources

Metal Stamping and Scrap Handling: benefits of the electric shaker (PDF)

  Read the full Metal Stamping and Scrap Handling feature on MPI shakers (PDF)

Downloads & Resources

• MPI M-10 electric shaker (18" max crossbar) spec sheet (PDF)
• MPI M-50 electric shaker (36" max crossbar) spec sheet (PDF)
• MPI M-200 rack and pinion shaker spec sheet (PDF)
• MPI M-10000 Series floor-mounted shaker spec sheet (PDF)
• Metal Stamping and Scrap Handling article on MPI electric shakers (PDF)

Contact & Ordering

Need help picking the right model or getting a quote? Provide these details:

• Press make, model and tonnage
• Bolster size and T-slot dimensions
• Crossbar width needed and distance between the die uprights
• Scrap type, size and approximate volume, and whether parts are oily
• Where the scrap goes next (hopper, conveyor or central scrap system)
• For M-10000 systems: route length, pit or floor layout, and available power

Contact PRI to discuss specs, lead times, and installation support.
